6D38 22UH SMD Coil

6D38 22UH SMD Coil

6D38 22UH SMD Coil Description

6D38 22UH SMD Coil is a high-performance surface-mount device that offers exceptional inductance stability, making it a reliable choice for a variety of electronic applications. This compact coil is designed with precision to ensure efficient energy storage and noise filtering capabilities, essential for modern electronic circuits. Whether you are designing power supplies, RF circuits, or other electronic systems, the 6D38 22UH SMD Coil is engineered to meet the industry's demanding standards.

6D38 22UH SMD Coil Features

• Inductance: 22µH
• Current Rating: 1.5A
• DC Resistance: 0.05Ω
• Package Type: SMD
• Operating Temperature Range: -40°C to +125°C
• Core Material: Ferrite
• Dimensions: 6.0mm x 6.0mm x 3.8mm

6D38 22UH SMD Coil Applications

• Power Supply Filtering: Ideal for smoothing out voltage fluctuations in power supply lines.
• RF Circuits: Perfect for tuning and filtering in radio frequency applications.
• DC-DC Converters: Enhances the performance of converters by providing stable inductance.
