2SC3686 TO-3P 1500V 7A 120W NPN Transistor

2SC3686 TO-3P 1500V 7A 120W NPN Transistor

2SC3686 TO-3P 1500V 7A 120W NPN Transistor Description

The 2SC3686 is a high-performance NPN transistor designed for use in a wide range of electronic applications. Encased in a TO-3P package, it is ideal for power amplification tasks requiring high voltage and current handling capabilities. With a robust 1500V collector-emitter voltage and a continuous current of 7A, this transistor is suitable for industrial and commercial environments. Offering a maximum power dissipation of 120W, the 2SC3686 ensures efficient thermal management and reliability in demanding circuits.

2SC3686 TO-3P 1500V 7A 120W NPN Transistor Features

• High Voltage Capability: Supports up to 1500V collector-emitter voltage, ensuring robust performance in high-voltage applications.
• Current Handling: Capable of delivering up to 7A of continuous current, making it suitable for high-current circuits.
• Power Dissipation: Efficient thermal design allows for 120W maximum power dissipation, enhancing durability under heavy loads.
• Durable Package: Encased in a TO-3P package, providing excellent heat dissipation and mechanical stability.
• High Gain: Offers significant current amplification, ideal for signal boosting in various applications.
• Reliable Performance: Designed for consistency in demanding electronic environments.
• Low Saturation Voltage: Ensures minimal power loss and efficient operation in switching applications.

2SC3686 TO-3P 1500V 7A 120W NPN Transistor Applications

• Power Amplifiers: Utilized in audio and RF power amplifiers for high-fidelity sound and signal transmission.
• Switching Power Supplies: Ideal for high-efficiency DC-DC converters and power management systems.
• Motor Control: Suitable for driving motors in industrial automation and robotics applications.
